A-B 1411-600-601 Model 600 Split Core Current Transformer, Ratio 600:5
The A-B 1411-600-601 Model 600 is an advanced split-core current transformer designed for industrial applications. It provides precise measurements with a ratio of 600:5, ensuring accurate and reliable data for your control systems.
Manufacturer:A-B
Model:1411-600-601
Type:Split Core CT
Ratio:600:5
Input Voltage Range:Up to 600V AC
Accuracy Class:Class 0.5
Output:5A
Frequency Range:50/60Hz
Operating Temperature Range:-25°C to +70°C
Protection Rating:IP20
Dimensions (H x W x D):4.33 in x 2.36 in x 1.57 in
Weight:0.3 lbs
The A-B Model 600 Split Core Current Transformer is meticulously engineered for demanding industrial applications. Its split core design allows for easy installation around existing conductors without the need for circuit interruption, enhancing flexibility and efficiency in installation processes.
This transformer features a ferrite core which provides excellent magnetic properties, ensuring high accuracy and minimal phase error even under varying load conditions. With an accuracy class of 0.5, it delivers reliable and consistent performance, making it suitable for critical monitoring and control systems.
Designed with durability in mind, the A-B Model 600 is built to withstand harsh industrial environments, operating within a wide temperature range from -40°C to +85°C. This robust construction guarantees longevity and reliable operation in challenging conditions.
Its compact size and lightweight design make it ideal for installations where space is limited, while the secondary output of 5A ensures compatibility with a wide range of measuring instruments and protective relays. The insulation class of Class B further enhances its safety and reliability.
To install, simply open the split core around the conductor, position it accurately, and close it securely. This ease of use makes the A-B Model 600 an indispensable tool for electricians, engineers, and maintenance personnel looking for a reliable current measurement solution.
