GE 369-HI-0-M-0-E-0 – Advanced Motor Management Relay for Industrial Control Systems

GE 369-HI-0-M-0-E-0 – Advanced Motor Management Relay for Industrial Control Systems

    The GE 369-HI-0-M-0-E-0 is a sophisticated motor management relay designed for industrial applications. It offers comprehensive protection and monitoring capabilities, ensuring reliable operation and timely alerts for potential issues.

# of Digital/Switch Inputs:6 optically isolated

Ambient Humidity Maximum:Up to 95% non condensing

Control Power nominal:20 VA

Control Power maximum:65 VA

Dimensions approx:11.5 in H x 5.5 in W x 8.5 in L

Fuse:3.15 A H 250 V

Maximum Altitude:2000 m (max)

Phase Current Inputs:1 A and 5 A secondary

Weight approx:10 lbs

Ground Current Input Frequency:20 to 100 Hz

Insulation Class:Class I

Phase Current Input Conversion:True RMS, 1.04 ms/sample

    The GE 369-HI-0-M-0-E-0 is an advanced motor management relay engineered to protect and monitor your industrial motors efficiently. With its robust design, it supports up to six digital or switch inputs, each optically isolated to prevent interference. Its ambient humidity tolerance ensures reliable operation even under harsh conditions. Designed for energy efficiency, this relay operates within a nominal control power range of 20 VA, with a maximum of 65 VA. The relay is built to withstand high altitudes up to 2000 meters, making it ideal for industrial environments where standard equipment might fail. Equipped with true RMS phase current input conversion, it ensures accurate measurements and responses, contributing to the longevity of your motors. Whether you’re managing a small facility or a large industrial complex, the GE 369-HI-0-M-0-E-0 is a valuable asset in safeguarding your investment.
