GE 369-HI-R-M-F-E-H-E Motor Management Relay with Enhanced Diagnostics

GE 369-HI-R-M-F-E-H-E Motor Management Relay with Enhanced Diagnostics

    The GE 369-HI-R-M-F-E-H-E is a high-performance Motor Management Relay designed for industrial applications. It provides advanced monitoring and diagnostic capabilities to ensure optimal performance and protection of your motor systems.

Control Power Range:110 to 250 VDC, 100 to 240 VAC at 50/60 Hz

# of Digital/Switch Inputs:6 optically isolated

# of Recordable Events:512

Fuse:3.15 A H 250 V

Maximum Altitude:2000 m (max)

Phase Current Inputs:1 A and 5 A secondary

RTD Inputs:3 wire, 100 Ω platinum, 100 Ω nickel, 120 Ω nickel,10 Ω copper

Dimensions:approx : 29.6cm H x 10.7cm W x 20.5cm L

Weight:approx. 10 lbs

Insulation Class:Class I

    The GE 369-HI-R-M-F-E-H-E Motor Management Relay offers advanced monitoring and protection for motors and their associated systems. Featuring a robust design, it is capable of handling control power ranges from 110 to 250 VDC and 100 to 240 VAC, ensuring reliable performance across various applications. With six optically isolated digital switch inputs, it provides precise control and monitoring capabilities. The unit is equipped with a fiber optic port, enhancing communication and data transfer efficiency. Its built-in metering package allows for comprehensive system monitoring, while the enhanced diagnostic features provide real-time insights into motor health. The relay’s design is hardened for use in harsh chemical environments, making it ideal for industries where durability is paramount. The user-friendly faceplate display offers clear, intuitive operation, making it simple for operators to manage and maintain the system. Ideal for applications requiring stringent control and protection, the GE 369-HI-R-M-F-E-H-E ensures optimal motor performance and extended equipment lifespan.
