GE F35-G00-HKH-F8R-H6N-M8R-P6N-U8M-W6N – Five/Six Feeder Management and Protection Unit
The GE F35-G00-HKH-F8R-H6N-M8R-P6N-U8M-W6N is a versatile protection system designed to monitor, manage, and safeguard up to five distribution feeder systems. Its advanced features and compact design make it ideal for industrial control environments.
# of FlexElements:16
AC Voltage Withstand:Continuous at 260 V to neutral 1 min/hr at 420 V to neutral
Maximum Altitude:2000 m
Maximum Oscillography Records:64
Pollution Degree:II
RTD Input Types:3-wire; 100 Ω Platinum, 10 Ω Copper, 100 and 120 Ω Nickel
Sampling Frequency:64 samples per power cycle
# of Direct Output Points:32
# of Wattmetric Zero-Sequence Directional Elements:4
Ingress Protection:IP20 front, IP10 back
Manual:1601-0106-AE1
Negative Sequence TOC Pickup Level:0.020 to 30.000 pu in steps of 0.001
Operating Temperature:–40 to 60°C
Phase Undervoltage Level Accuracy:±0.5% of reading from 10 to 208 V
The General Electric F35-G00-HKH-F8R-H6N-M8R-P6N-U8M-W6N is meticulously engineered to provide reliable protection and management for industrial electrical systems.
This compact relay system is capable of handling complex monitoring tasks across multiple feeders, ensuring optimal performance and safety in various applications.
Key design features include its robust construction, high precision metering capabilities, and flexible configuration options.
The system supports direct output points and advanced wattmetric zero-sequence directional elements, making it a superior choice for demanding industrial environments.
Its ingress protection ratings ensure durability and reliability under challenging conditions, while a wide operating temperature range allows for deployment in diverse climates.
With customizable settings like SECURITY, DISPLAY PROPERTIES, and TELEPROTECTION, users can tailor the system to meet their specific needs.
