GE IS200TRLYH1BGF Control System – Relay Terminal Board

GE IS200TRLYH1BGF Control System – Relay Terminal Board

    This relay terminal board, designed by GE, is an essential component for control systems, providing reliable relay outputs. It is specially tailored for industrial automation applications.

Manufacturer:General Electric (GE)

Series:Mark VI IS200

Product Type:Terminal Relay Card

Model Number:IS200TRLYH1BGF

Relay Count:48 Terminals

Relay Configuration:6 Relays (Gray and Black with Transparent Covers)

Terminal Blocks:2 Terminal Blocks with 24 Terminals Each

Protection Components:6 Metal Oxide Varistors (MOVs), 1 Additional MOV in Lower Left Corner

Transistor Count:6 Transistors (Paired with MOVs)

Capacitor Count:6 Pure Blue Capacitors

Integrated Circuits:Multiple ICs Distributed Across Board

Compatibility:GE Mark VI Series Control Systems

Application:Industrial Automation, Turbine Control, Electrical Equipment Monitoring and Control

    The GE IS200TRLYH1BGF is an essential component for GE’s Mark VI series turbine control systems, ensuring reliable relay signal management and terminal connections.

    This relay terminal board features two long black terminal blocks, each housing 24 numbered terminals, allowing for organized and efficient wire connections.

    The central area of the board is occupied by a series of vertically aligned relays with transparent covers, providing visibility for monitoring the status of relay operations.

    Additionally, six black transistors are positioned strategically around the relays, contributing to the board’s robust functionality and performance.

    Designed with durability and precision in mind, the GE IS200TRLYH1BGF ensures seamless integration into existing industrial control systems, enhancing overall system efficiency and reliability.
