National Instruments PXIe-4464 Dynamic Signal Acquisition Module
The NI PXIe-4464 is a high-performance dynamic signal analyzer designed for vibration testing and acoustic measurement applications in industrial control systems. It offers exceptional accuracy and reliability, making it ideal for engineers and researchers in the field.
Module Type:Dynamic Signal Acquisition
Interface:PXI Express
Channels:8 differential or 16 single-ended analog input channels
Sample Rate:up to 102.4 kS/s per channel
Resolution:24-bit
Input Range:+/-10 V
Anti-Aliasing Filter:Programmable 8th-order
Connectors:BNC and LEMO connectors
Compatibility:Works with NI LabVIEW, MATLAB, and other leading software platforms.
The National Instruments PXIe-4464 is a powerful dynamic signal acquisition module designed to meet the demands of high-performance test and measurement applications. With its 8 differential or 16 single-ended channels, this module provides exceptional versatility for a wide range of testing scenarios. Each channel supports a sampling rate of up to 102.4 kS/s, ensuring accurate and timely data collection. The 16-bit resolution guarantees a high level of precision in your measurements, while the +/-5V input range allows for flexible signal handling.
Key design highlights include an 8th order Butterworth anti-aliasing filter, which minimizes unwanted frequencies and ensures clean, clear data. The BNC connectors offer reliable connections, making it easy to integrate with other systems and equipment. The PXIe-4464 is fully compatible with leading software platforms like NI LabVIEW, MATLAB, and Python, allowing for seamless data analysis and visualization.
By utilizing the PXI Express architecture, the module offers enhanced performance and flexibility, making it an ideal choice for demanding industrial control applications. Its robust design and compatibility with industry-standard tools make it a top choice for engineers and researchers looking for a reliable solution for their dynamic signal acquisition needs.
