GE Multilin 369-HI-0-M-F-E-0 Motor Management Relay with Metering Package, Comprehensive Monitoring & Protection
The GE Multilin 369-HI-0-M-F-E-0 is a motor management relay designed for comprehensive monitoring and control of motor operations. It provides detailed metering data on various electrical parameters, ensuring optimal performance and reliability.
Voltage Range:50-300 VDC / 40-265 VAC
# of Metered Quantities:Phase currents, current demand amps, motor load x fLA, unbalanced current %, ground current amps, switch status, relay output status, RTD temperature, backspin frequency Hz, phase and line voltages, frequency Hz, power factor lead/lag, real power and real power demand watts, reactive power and reactive power demand vars, apparent power and apparent power demand VA, real power consumption Mwh, reactive power consumption/generation
Digital/Switch Inputs:6 optically isolated
Ambient Humidity:Maximum up to 95% non-condensing
Dimensions:approx: 11.5 in H x 5.5 in W x 8.5 in L
Display Version:Enhanced
Fuse:3.15 A H 250 V
Input Power:110-250VDC / 100-240VAC
Weight:8 lbs
The GE Multilin 369-HI-0-M-F-E-0 is an advanced motor management relay designed for demanding industrial environments. With its extensive metering capabilities, it monitors critical parameters like phase currents, motor load, ground current, and more, ensuring optimal performance and protection of your motors. The relay includes 6 optically isolated digital inputs for versatile connectivity options, and its enhanced display provides clear, real-time operational data. Designed with robust materials, the relay is capable of operating under up to 95% non-condensing humidity, making it suitable for various environmental conditions. With dimensions of approximately 11.5 inches high, 5.5 inches wide, and 8.5 inches long, it fits seamlessly into existing control systems. The lightweight design at 8 lbs ensures easy installation and maintenance. For further details and technical specifications, please refer to the GEK-106288Y 369 Motor Management Instruction Manual.
