Schneider Electric HMIGF1-10TVD-000 HMI – Operator Dialogue Touchscreen for Industrial Control

Schneider Electric HMIGF1-10TVD-000 HMI – Operator Dialogue Touchscreen for Industrial Control

    The Schneider Electric HMI GF1-10TVD-000 is a robust Human-Machine Interface designed for industrial applications. It offers intuitive touch screen operation, enhanced visibility with a wide 10-inch display, and supports various communication protocols including Modbus and Ethernet. Ideal for real-time data visualization and control.

Brand:Schneider Electric

Model:GF1-10TVD-000

Display Size:10 inches

Resolution:800×480 pixels

Color Depth:65536 colors

Touchscreen:Resistive

Communication Protocols:Modbus, Ethernet, RS-232, RS-485

Supply Voltage:24Vdc

Memory Capacity:32MB Flash, 16MB RAM

Environmental Protection:IP65 / IP67 / NEMA 4X

Dimensions:250 x 175 x 55 mm

Weight:Approximately 1.2 kg

    The Schneider Electric HMI GF1-10TVD-000 represents the pinnacle of human-machine interaction in the industrial sector. Featuring a vibrant 10-inch WVGA resistive touchscreen, this HMI offers crystal-clear visuals under various lighting conditions, ensuring optimal visibility even in challenging environments. Its rugged design, rated at IP65 / IP67 and NEMA 4X standards, makes it resilient against dust, water, and other environmental factors, making it perfect for outdoor and harsh indoor installations.

    Equipped with a comprehensive array of communication interfaces including RS-232, RS-485, Ethernet, and USB ports, the HMI GF1-10TVD-000 facilitates seamless integration into existing control systems, allowing for flexible networking capabilities. The device’s 32MB flash memory and 4MB RAM provide ample storage space for applications and data logging, ensuring smooth operation and reliable performance.

    Ease of installation is further enhanced by the inclusion of standard DIN rail mounting options, enabling quick and secure integration within control cabinets. The HMI GF1-10TVD-000 is powered by a 24Vdc power supply, making it compatible with a wide range of industrial power systems. Its user-friendly interface and customizable screens make it a versatile tool for operators and engineers alike, streamlining process monitoring and control tasks.
