Tektronix AFG1022 Arbitrary Function Generator
The Tektronix AFG1022 Arbitrary Function Generator offers versatile signal generation capabilities essential for testing and validating electronic circuits. It supports sine, square, triangle, ramp, and arbitrary waveforms, making it ideal for a wide range of applications from basic electronics education to advanced research and development.
Output Channels:2
Frequency Range:0.1 µHz to 20 MHz
Waveform Types:Sine, Square, Triangle, Ramp, Pulse, DC, Arbitrary
Sampling Rate:250 MSa/s
Vertical Resolution:12-bit
Memory Depth per Channel:16 kSa
Amplitude Range:+/- 10 V (into 50 Ohms)
DC Offset:+/- 10 V
Resolution Bandwidth:Up to 20 MHz
Design Highlights: The AFG1022 boasts a user-friendly interface and intuitive software, allowing for easy waveform generation and editing. With its robust performance and extensive functionality, this arbitrary function generator provides unparalleled precision and reliability.
Material: The device is constructed with high-quality materials ensuring durability and long-lasting performance under rigorous testing conditions. The front panel features a large color display and intuitive controls for ease of use.
Usage Method: Simply connect the AFG1022 to your test equipment or system via the BNC outputs. Use the front panel controls or software interface to configure waveforms and adjust settings according to your application requirements.
Warranty: Each Tektronix AFG1022 comes with a standard warranty covering defects in material and workmanship. Our support team is available to assist you with any questions or issues you may encounter.
Compatibility: The AFG1022 is compatible with a wide variety of systems and devices, including oscilloscopes, spectrum analyzers, and more. It integrates seamlessly into existing setups and is an indispensable addition to any electronics lab.
