TRICONEX 3704E TMR AI Module, 64 Input Points, High Precision
The TRICONEX 3704E is a high-precision analog input module designed for industrial control systems. It offers reliable performance with 64 input points and an update rate of 75ms. Ideal for applications requiring precise measurement and monitoring.
Model Number:3704E
Manufacturer:Triconex
Type:Analog I/O Module
Voltage Range:0-5V or 0-10V ±6%
Input Points:64
Input Update Rate:75 ms
Resolution:12 bits
Accuracy:< 0.25% of FSR from 0° to 60°C
Input Resistance:30 MΩ (DC), min
Power-Off Resistance:30 kΩ (DC), typical
Common Mode Rejection:n/a
Common Mode Range:n/a
Leg-to-Leg Isolation:200 kΩ, typical
Normal Mode Rejection:-1 dB @ 8Hz -12 dB @ 60Hz -18 dB @ 120Hz
Input Overrange:Supported
The TRICONEX 3704E Analog Input Module is designed to provide robust and reliable data acquisition capabilities essential for industrial automation systems. Its TMR architecture ensures maximum system integrity and uptime by eliminating single point failures.
With its ability to handle up to 64 input points, this module offers extensive coverage for a variety of sensors and transmitters, making it ideal for complex industrial applications.
This module supports voltage ranges of 0-5V or 0-10V with a tolerance of ±6%, offering flexibility in interfacing with a wide range of sensor outputs.
Featuring a high resolution of 12 bits and an accuracy of less than 0.25% of full-scale reading across a temperature range from 0°C to 60°C, the 3704E ensures precise measurement and reliable performance.
The design incorporates commoned input points, which simplifies wiring and installation, reducing potential points of failure and enhancing system reliability.
